Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Pinarello 2026 X3 105 Di2 Road Bike
Pinarello 2026 X3 105 Di2 Road Bike
Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Pinarello 2026 X3 105 Di2 Road Bike Indicative of Frame Only
Indicative of Frame Only
Click Here for Larger Image
Pinarello 2026 X3 105 Di2 Road Bike 5
Pinarello 2026 X3 105 Di2 Road Bike 6
Pinarello 2026 X3 105 Di2 Road Bike 1
Pinarello 2026 X3 105 Di2 Road Bike 2
Pinarello 2026 X3 105 Di2 Road Bike 7
Pinarello 2026 X3 105 Di2 Road Bike 8
Pinarello 2026 X3 105 Di2 Road Bike 3
Pinarello 2026 X3 105 Di2 Road Bike 4

Pinarello 2026 X3 105 Di2 Road Bike

Pricing and Order Section

Mfg PartNum:
$5,000.00
MSRP: $5,000.00
That's off
In Stock
Ships Free!
Earn $150.00 in VIP credit. Click to Learn More.
15000
POINTS
This size is not eligible for VIP points
Price matches are is not eligible for VIP points


Description

True Cycling Experience

The 2026 Pinarello X3 105 Di2 was designed for casual and competitive riders who appreciate a bike of quality and distinction. Not every cyclist wants to push their body to the extreme trying to fit on a bike designed for the pro peloton, so Pinarello went back to the drawing board for the Pinarello X and designed a new geometry that offers all-day comfort without renouncing their legendary performance DNA. Thanks to a combination of specifically-selected materials, unique geometry, and a truly innovative rear-end, the Pinarello X series strikes the perfect balance between reactivity, performance and comfort.

The secret of T700 Toray Carbon is to maintain reactivity and performances but to offer a higher dampening to absorb all road vibration. More comfort, more fun. It's made Asymmetrically because while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason all Pinarello X frames are optimized to compensate these unbalanced forces.

The Onda Fork is a distinctive Pinarello Technology in use since 2000. The shape of the fork delivers precise turning abilities, stability and reduction of longitudinal and lateral shocks. The rear Flex Stays are another exclusive Pinarello design that absorbs vibrations without reducing the responsiveness of the rear triangle.

Features:

  • Carbon T700 UD Frame
  • Onda Fork
  • Flex Stays
  • Pinarello X Asymmetric Design
  • Shimano 105 Di2 2x

Build:

  • Frame: Torayca T700 UD Carbon, TiCR™ internal cable routing, Italian BB, 12x142mm TA
  • Fork: Onda fork, tapered head tube, 12x100mm TA
  • Handlebar: MOST Jaguar XA Aero TiCR; 430-515: 420mm; 530-545: 440mm; 560-595: 460mm
  • Bar Tape: MOST Ultragrip Evo 3mm - Black
  • Stem: MOST Tiger Aero Alu TiCR; 430-465: 90mm; 500: 100mm; 515-530: 110mm; 545-560: 120mm; 575-595: 130mm
  • Shift/Brake Levers: Shimano 105 Di2 ST-R7170 2x12s
  • Brakes: Shimano 105 BR-R7170, 160mm F/R
  • Front Derailleur: Shimano 105 Di2 FD-R7150
  • Rear Derailleur: Shimano 105 Di2 RD-R7150
  • Crankset: Shimano 105 FC-R7100 50/34t; 430-515: 170mm; 530-560: 172.5mm; 575-595: 175mm
  • Cassette: Shimano CS-R7101 11-34t
  • Chain: Shimano CN-M7100 12s
  • Wheelset: DT Swiss A1800 30DB Spline
  • Tires: MOST Competition 34
  • Axles: MOST Ultra Light Custom Axle 12x100 & 12x142, tool free removal
  • Saddle: MOST Lynx
  • Exact components subject to availability. Photos are indicative of FRAME ONLY

  • Returns: This product is overweight and/or oversize and does not qualify for our fixed rate return shipping label. If you need to return this item, we can offer a return shipping label at our discounted shipping rates, or you can arrange for your own return shipping.

    Complete Bicycle Shipping - complete bikes ship to the Continental US (lower 48 states) for a flat rate of $79.99. To get a shipping quote to other locations, add the item to your shopping cart and enter your shipping location.

    B-Stock - This product has one or more B-Stock units available. These units can be purchased at a discount (see option select). B-Stock units were returned from other customers and may have missing or damaged packaging materials. These units are otherwise as new. The full manufacturer warranty applies. Click Here for more information.

    Please note: This product ships signature required.

    Specifications

    43cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00010

    46cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00011

    49cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00012

    51.5cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00013

    53cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00014

    54.5cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00015

    56cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00016

    58cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00017

    60cm - Impulse Grey Matte

    Mfg PartNum: D2017150206-00018
